Please send RFQ , we will respond immediately.
| Part Number | F4150R12KS4BOSA1 | F450R12KS4BOSA1 | F4100R12KS4BOSA1 |
|---|---|---|---|
| Manufacturer | Infineon Technologies | Infineon Technologies | Infineon Technologies |
| Product Status | Active | Discontinued at Digi-Key | Active |
| IGBT Type | - | - | - |
| Configuration | Three Phase Inverter | Three Phase Inverter | Three Phase Inverter |
| Voltage - Collector Emitter Breakdown (Max) | 1200 V | 1200 V | 1200 V |
| Current - Collector (Ic) (Max) | 180 A | 70 A | 130 A |
| Power - Max | 960 W | 355 W | 660 W |
| Vce(on) (Max) @ Vge, Ic | 3.75V @ 15V, 150A | 3.75V @ 15V, 50A | 3.75V @ 15V, 100A |
| Current - Collector Cutoff (Max) | 5 mA | 5 mA | 5 mA |
| Input Capacitance (Cies) @ Vce | 10 nF @ 25 V | 3.4 nF @ 25 V | 6.8 nF @ 25 V |
| Input | Standard | Standard | Standard |
| NTC Thermistor | Yes | Yes | Yes |
| Operating Temperature | -40°C ~ 125°C | -40°C ~ 125°C | -40°C ~ 125°C |
| Mounting Type | Chassis Mount | Chassis Mount | Chassis Mount |
| Package / Case | Module | Module | Module |
| Supplier Device Package | Module | Module | Module |
