| Part Number | CYW43362SKUBGT | CYW43362KUBGT |
|---|---|---|
| Manufacturer | Infineon Technologies | Infineon Technologies |
| Product Status | Discontinued at Digi-Key | Active |
| Type | TxRx + MCU | TxRx + MCU |
| RF Family/Standard | WiFi | WiFi |
| Protocol | 802.11b/g/n | 802.11b/g/n |
| Modulation | 16QAM, 64QAM, BPSK, QPSK | 16QAM, 64QAM, BPSK, CCK, DSSS, QPSK, OFDM |
| Frequency | 2.4GHz | 2.4GHz |
| Data Rate (Max) | 72Mbps | 72Mbps |
| Power - Output | 18.5dBm | 18.5dBm |
| Sensitivity | -97dBm | -97dBm |
| Memory Size | 448kB ROM, 240kB RAM | 448kB ROM, 240kB RAM |
| Serial Interfaces | JTAG, SPI, UART | JTAG, SPI, UART |
| GPIO | 5 | 5 |
| Voltage - Supply | 3.3V | 1.2V ~ 3.3V |
| Current - Receiving | 52mA ~ 59mA | 52mA ~ 59mA |
| Current - Transmitting | 260mA ~ 320mA | 260mA ~ 320mA |
| Operating Temperature | -30°C ~ 85°C | -30°C ~ 85°C |
| Mounting Type | Surface Mount | Surface Mount |
| Package / Case | 69-UFBGA, WLBGA | 69-UFBGA, WLBGA |
| Supplier Device Package | 69-WLBGA (4.52x2.92) | 69-WLBGA (4.52x2.92) |
