| Part Number | CYW43340XKUBGT | CYW43340HKUBGT | CYW43340XKUBG |
|---|---|---|---|
| Manufacturer | Infineon Technologies | Infineon Technologies | Infineon Technologies |
| Product Status | Active | Obsolete | Obsolete |
| Type | TxRx + MCU | TxRx + MCU | TxRx + MCU |
| RF Family/Standard | Bluetooth, WiFi | Bluetooth, WiFi | Bluetooth, WiFi |
| Protocol | 802.11a/b/g/n, Bluetooth v4.0 | 802.11a/b/g/n, Bluetooth v4.0 | 802.11b/g/n, Bluetooth v4.0 |
| Modulation | 8DPSK, DQPSK, GFSK | 8DPSK, DQPSK, GFSK | 4DQPSK, 8DPSK, GFSK |
| Frequency | 2.4GHz, 5GHz | 2.4GHz, 5GHz | 2.4GHz |
| Data Rate (Max) | 150Mbps | 150Mbps | 150Mbps |
| Power - Output | 11dBm | 11dBm | 13dBm |
| Sensitivity | -94.5dBm | -94.5dBm | -99dBm |
| Memory Size | 640kB ROM, 512kB SRAM | 640kB ROM, 512kB SRAM | 680kB ROM, 173kB RAM |
| Serial Interfaces | I²S, SPI, UART | I²C, I²S, JTAG, SPI, UART | I²S, SPI, UART |
| GPIO | 8 | 8 | 8 |
| Voltage - Supply | 1.2V ~ 3.3V | 1.2V ~ 3.3V | 2.3V ~ 4.8V |
| Current - Receiving | 44.4mA ~ 57.7mA | 44.4mA ~ 57.7mA | 39mA |
| Current - Transmitting | 254mA ~ 325mA | 254mA ~ 325mA | 60mA |
| Operating Temperature | -30°C ~ 85°C | -30°C ~ 85°C | -30°C ~ 85°C |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount |
| Package / Case | 141-UFBGA, WLBGA | 141-UFBGA, WLBGA | 141-UFBGA, WLBGA |
| Supplier Device Package | 141-WLBGA (5.67x4.47) | 141-WLBGA (5.67x4.47) | 141-WLBGA (5.67x4.47) |
