| Part Number | BTS710404ESEXUMA1 | BTS710404ESAXUMA1 |
|---|---|---|
| Manufacturer | Infineon Technologies | Infineon Technologies |
| Product Status | Active | Active |
| Switch Type | General Purpose | General Purpose |
| Number of Outputs | 4 | 4 |
| Ratio - Input:Output | 1:2 | 1:1 |
| Output Configuration | High Side | High Side |
| Output Type | N-Channel | N-Channel |
| Interface | SPI | SPI |
| Voltage - Load | 6V ~ 18V | 6V ~ 18V |
| Voltage - Supply (Vcc/Vdd) | Not Required | Not Required |
| Current - Output (Max) | 3A | 3A |
| Rds On (Typ) | 22.5mOhm | 22.5mOhm |
| Input Type | Non-Inverting | Non-Inverting |
| Features | - | - |
| Fault Protection | Over Current, Over Voltage, Short Circuit, UVLO | Over Current, Over Voltage, Short Circuit, UVLO |
| Operating Temperature | -40°C ~ 150°C (TJ) | -40°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount | Surface Mount |
| Supplier Device Package | PG-TSDSO-24 | PG-TSDSO-24 |
| Package / Case | 24-TSSOP (0.154", 3.90mm Width) Exposed Pad | 24-TSSOP (0.154", 3.90mm Width) Exposed Pad |
