| Part Number | BSP612PH6327XTSA1 | BSP613PH6327XTSA1 |
|---|---|---|
| Manufacturer | Infineon Technologies | Infineon Technologies |
| Product Status | Obsolete | Active |
| FET Type | - | P-Channel |
| Technology | - | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | - | 60 V |
| Current - Continuous Drain (Id) @ 25°C | 3A (Ta) | 2.9A (Ta) |
| Drive Voltage (Max Rds On, Min Rds On) | - | 10V |
| Rds On (Max) @ Id, Vgs | - | 130mOhm @ 2.9A, 10V |
| Vgs(th) (Max) @ Id | - | 4V @ 1mA |
| Gate Charge (Qg) (Max) @ Vgs | - | 33 nC @ 10 V |
| Vgs (Max) | - | ±20V |
| Input Capacitance (Ciss) (Max) @ Vds | - | 875 pF @ 25 V |
| FET Feature | - | - |
| Power Dissipation (Max) | - | 1.8W (Ta) |
| Operating Temperature | - | -55°C ~ 150°C (TJ) |
| Mounting Type | - | Surface Mount |
| Supplier Device Package | - | PG-SOT223-4 |
| Package / Case | - | TO-261-4, TO-261AA |
