| Part Number | BSL207NL6327 | BSL205NL6327 |
|---|---|---|
| Manufacturer | Infineon Technologies | Infineon Technologies |
| Product Status | Active | Active |
| FET Type | 2 N-Channel (Dual) | 2 N-Channel (Dual) |
| FET Feature | Logic Level Gate | Logic Level Gate |
| Drain to Source Voltage (Vdss) | 20V | 20V |
| Current - Continuous Drain (Id) @ 25°C | 2.1A | 2.5A |
| Rds On (Max) @ Id, Vgs | 70mOhm @ 2.1A, 4.5V | 50mOhm @ 2.5A, 4.5V |
| Vgs(th) (Max) @ Id | 1.2V @ 11µA | 1.2V @ 11µA |
| Gate Charge (Qg) (Max) @ Vgs | 2.1nC @ 4.5V | 3.2nC @ 4.5V |
| Input Capacitance (Ciss) (Max) @ Vds | 419pF @ 10V | 419pF @ 10V |
| Power - Max | 500mW | 500mW |
| Operating Temperature | -55°C ~ 150°C (TJ) | -55°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount | Surface Mount |
| Package / Case | SOT-23-6 Thin, TSOT-23-6 | SOT-23-6 Thin, TSOT-23-6 |
| Supplier Device Package | PG-TSOP6-6 | PG-TSOP6-6 |
