| Part Number | BGS12PL6E6327XTSA1 | BGS12SL6E6327XTSA1 | BGS12P2L6E6327XTSA1 |
|---|---|---|---|
| Manufacturer | Infineon Technologies | Infineon Technologies | Infineon Technologies |
| Product Status | Last Time Buy | Obsolete | Active |
| RF Type | GSM, LTE, W-CDMA | GSM, LTE, W-CDMA | GSM, LTE, W-CDMA |
| Topology | Reflective | Reflective | - |
| Circuit | SPDT | SPDT | SPDT |
| Frequency Range | 100MHz ~ 4GHz | 100MHz ~ 6GHz | 50MHz ~ 6GHz |
| Isolation | 22dB | 15dB | 27dB |
| Insertion Loss | 0.77dB | 1.5dB | 0.51dB |
| Test Frequency | 3.8GHz | 6GHz | 5.925GHz |
| P1dB | - | - | - |
| IIP3 | - | - | 74dBm |
| Features | Single Line Control | Single Line Control | - |
| Impedance | 50Ohm | 50Ohm | 50Ohm |
| Voltage - Supply | 2.4V ~ 3.6V | 2.4V ~ 3.6V | 1.65V ~ 3.4V |
| Operating Temperature | -40°C ~ 85°C | -30°C ~ 85°C | -40°C ~ 85°C (TA) |
| Package / Case | 6-XFDFN | 6-XFDFN | 6-XFDFN |
| Supplier Device Package | TSLP-6-4 | TSLP-6-4 | PG-TSLP-6-4 |
