| Part Number | BGA715L7E6327XTSA1 | BGA615L7E6327XTSA1 | BGA711L7E6327XTSA1 | BGA713L7E6327XTSA1 |
|---|---|---|---|---|
| Manufacturer | Infineon Technologies | Infineon Technologies | Infineon Technologies | Infineon Technologies |
| Product Status | Obsolete | Obsolete | Obsolete | Obsolete |
| Frequency | 1575MHz | 1.575GHz | 1.9GHz, 2.1GHz | 728MHz ~ 768MHz |
| P1dB | -15.5dBm | - | -8dBm | -7dBm |
| Gain | 20dB | 18dB | 17dB | 15.5dB |
| Noise Figure | 0.75dB | 0.9dB | 1.1dB | 1.1dB |
| RF Type | GPS | GPS | UMTS | UMTS |
| Voltage - Supply | 1.5V ~ 3.3V | 2.4V ~ 3.2V | 2.6V ~ 3V | 2.6V ~ 3V |
| Current - Supply | 3.3mA | 5.6mA | 3.6mA | 4.8mA |
| Test Frequency | 1.575GHz | - | 2.1GHz | 700MHz |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount | Surface Mount |
| Package / Case | 6-XFDFN Exposed Pad | 6-XFDFN Exposed Pad | 6-XFDFN Exposed Pad | 6-XFDFN Exposed Pad |
| Supplier Device Package | PG-TSLP-7-1 | PG-TSLP-7-1 | PG-TSLP-7-1 | PG-TSLP-7-1 |
