| Part Number | BFP 420F E6327 | BFP 520F E6327 | BFP 720F E6327 |
|---|---|---|---|
| Manufacturer | Infineon Technologies | Infineon Technologies | Infineon Technologies |
| Product Status | Obsolete | Obsolete | Obsolete |
| Transistor Type | NPN | NPN | NPN |
| Voltage - Collector Emitter Breakdown (Max) | 5V | 3.5V | 4.7V |
| Frequency - Transition | 25GHz | 45GHz | 45GHz |
| Noise Figure (dB Typ @ f) | 1.1dB @ 1.8GHz | 0.95dB @ 1.8GHz | 0.4dB ~ 1dB @ 150MHz ~ 10GHz |
| Gain | 19.5dB | 22.5dB | 10.5dB ~ 28dB |
| Power - Max | 160mW | 100mW | 100mW |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 60 @ 5mA, 4V | 70 @ 20mA, 2V | 160 @ 13mA, 3V |
| Current - Collector (Ic) (Max) | 35mA | 40mA | 25mA |
| Operating Temperature | 150°C (TJ) | 150°C (TJ) | 150°C (TJ) |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount |
| Package / Case | 4-SMD, Flat Leads | 4-SMD, Flat Leads | 4-SMD, Flat Leads |
| Supplier Device Package | 4-TSFP | 4-TSFP | 4-TSFP |
