Please send RFQ , we will respond immediately.
| Part Number | BCR 133F B6327 | BCR 133F E6327 | BCR 133 B6327 |
|---|---|---|---|
| Manufacturer | Infineon Technologies | Infineon Technologies | Infineon Technologies |
| Product Status | Obsolete | Obsolete | Discontinued at Digi-Key |
| Transistor Type | NPN - Pre-Biased | NPN - Pre-Biased | NPN - Pre-Biased |
| Current - Collector (Ic) (Max) | 100 mA | 100 mA | 100 mA |
| Voltage - Collector Emitter Breakdown (Max) | 50 V | 50 V | 50 V |
| Resistor - Base (R1) | 10 kOhms | 10 kOhms | 10 kOhms |
| Resistor - Emitter Base (R2) | 10 kOhms | 10 kOhms | 10 kOhms |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 30 @ 5mA, 5V | 30 @ 5mA, 5V | 30 @ 5mA, 5V |
| Vce Saturation (Max) @ Ib, Ic | 300mV @ 500µA, 10mA | 300mV @ 500µA, 10mA | 300mV @ 500µA, 10mA |
| Current - Collector Cutoff (Max) | 100nA (ICBO) | 100nA (ICBO) | 100nA (ICBO) |
| Frequency - Transition | 130 MHz | 130 MHz | 130 MHz |
| Power - Max | 250 mW | 250 mW | 200 mW |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount |
| Package / Case | SOT-723 | SOT-723 | TO-236-3, SC-59, SOT-23-3 |
| Supplier Device Package | PG-TSFP-3 | PG-TSFP-3 | PG-SOT23 |
