| Part Number | AUIRFN8458TR | AUIRFN8459TR |
|---|---|---|
| Manufacturer | Infineon Technologies | Infineon Technologies |
| Product Status | Active | Active |
| FET Type | 2 N-Channel (Dual) | 2 N-Channel (Dual) |
| FET Feature | Standard | Standard |
| Drain to Source Voltage (Vdss) | 40V | 40V |
| Current - Continuous Drain (Id) @ 25°C | 43A (Tc) | 50A |
| Rds On (Max) @ Id, Vgs | 10mOhm @ 26A, 10V | 5.9mOhm @ 40A, 10V |
| Vgs(th) (Max) @ Id | 3.9V @ 25µA | 3.9V @ 50µA |
| Gate Charge (Qg) (Max) @ Vgs | 33nC @ 10V | 60nC @ 10V |
| Input Capacitance (Ciss) (Max) @ Vds | 1060pF @ 25V | 2250pF @ 25V |
| Power - Max | 34W (Tc) | 50W |
| Operating Temperature | -55°C ~ 175°C (TJ) | -55°C ~ 175°C (TJ) |
| Mounting Type | Surface Mount | Surface Mount |
| Package / Case | 8-PowerTDFN | 8-PowerTDFN |
| Supplier Device Package | PQFN (5x6) | PQFN (5x6) |
