| Part Number | 2ED2304S06FXUMA1 | 2ED2104S06FXUMA1 |
|---|---|---|
| Manufacturer | Infineon Technologies | Infineon Technologies |
| Product Status | Active | Active |
| Driven Configuration | - | Half-Bridge |
| Channel Type | - | Independent |
| Number of Drivers | - | 2 |
| Gate Type | - | IGBT, N-Channel MOSFET |
| Voltage - Supply | - | 10V ~ 20V |
| Logic Voltage - VIL, VIH | - | 1.1V, 1.7V |
| Current - Peak Output (Source, Sink) | - | 290mA, 700mA |
| Input Type | - | Non-Inverting |
| High Side Voltage - Max (Bootstrap) | - | 650 V |
| Rise / Fall Time (Typ) | - | 70ns, 35ns |
| Operating Temperature | - | -40°C ~ 125°C (TA) |
| Mounting Type | - | Surface Mount |
| Package / Case | - | 8-SOIC (0.154", 3.90mm Width) |
| Supplier Device Package | - | PG-DSO-8-69 |
