Please send RFQ , we will respond immediately.
| Part Number | UM-QP-1.5VCR3A(40) | UM-QP-1.5WCR3A(40) | UM-QP-1.5VCR3A(41) | UM-QJ-1.5VCR3A(40) |
|---|---|---|---|---|
| Manufacturer | Hirose Electric Co Ltd | Hirose Electric Co Ltd | Hirose Electric Co Ltd | Hirose Electric Co Ltd |
| Product Status | Active | Active | Active | Active |
| Connector Style | U.FL (UMCC) | U.FL (UMCC) | U.FL (UMCC) | U.FL (UMCC) |
| Connector Type | Plug, Female Socket | Plug, Female Socket | Plug, Female Socket | Jack, Male Pin |
| Contact Termination | Solder | Solder | Solder | Solder |
| Shield Termination | Crimp | Crimp | Crimp | Crimp |
| Impedance | 50Ohm | 50Ohm | 50Ohm | 50Ohm |
| Mounting Type | Free Hanging (In-Line) | Free Hanging (In-Line) | Free Hanging (In-Line) | Free Hanging (In-Line) |
| Mounting Feature | - | - | - | - |
| Cable Group | 1.5D-2V, 1.5D-HQEV, 1.5D-QEV | 1.5D-2W, 1.5D-HQEW, 1.5QEW | 1.5D-2V, 1.5D-HQEV, 1.5D-QEV | - |
| Fastening Type | Snap-On | Snap-On | Snap-On | Snap-On |
| Frequency - Max | 3 GHz | 3 GHz | 3 GHz | 2 GHz |
| Number of Ports | 1 | 1 | 1 | 1 |
| Features | - | - | - | - |
| Housing Color | Silver | Silver | Gold | Silver |
| Ingress Protection | - | - | - | - |
| Center Contact Material | Beryllium Copper | Beryllium Copper | Beryllium Copper | Brass |
