Please send RFQ , we will respond immediately.
| Part Number | UM-QLP-1.5-6(40) | UM-QLP-1.5-6(41) | UM-QLP-1.5W-6(40) |
|---|---|---|---|
| Manufacturer | Hirose Electric Co Ltd | Hirose Electric Co Ltd | Hirose Electric Co Ltd |
| Product Status | Active | Active | Active |
| Connector Style | U.FL (UMCC) | U.FL (UMCC) | U.FL (UMCC) |
| Connector Type | Plug, Female Socket | Plug, Female Socket | Plug, Female Socket |
| Contact Termination | Solder | Solder | Solder |
| Shield Termination | Crimp | Crimp | Crimp |
| Impedance | 50Ohm | 50Ohm | 50Ohm |
| Mounting Type | Free Hanging (In-Line), Right Angle | Free Hanging (In-Line), Right Angle | Free Hanging (In-Line), Right Angle |
| Mounting Feature | - | - | - |
| Cable Group | 1.5D-2V, 1.5D-HQEV, 1.5D-QEV | 1.5D-2V, 1.5D-HQEV, 1.5D-QEV | 1.5D-2W, 1.5D-HQEW, 1.5QEW |
| Fastening Type | Snap-On | Snap-On | Snap-On |
| Frequency - Max | 2 GHz | 2 GHz | 2 GHz |
| Number of Ports | 1 | 1 | 1 |
| Features | - | - | - |
| Housing Color | Silver | Silver | Silver |
| Ingress Protection | - | - | - |
| Center Contact Material | Beryllium Copper | Beryllium Copper | Beryllium Copper |
