| Part Number | RPC2-12RB-7P(71) | RPC2-12RB-3P(71) | RPC2-12RB-7P(01) |
|---|---|---|---|
| Manufacturer | Hirose Electric Co Ltd | Hirose Electric Co Ltd | Hirose Electric Co Ltd |
| Product Status | Last Time Buy | Last Time Buy | Obsolete |
| Connector Type | Receptacle, Male Pins | Receptacle, Male Pins | - |
| Number of Positions | 7 | 3 | - |
| Shell Size - Insert | 12 | 12 | - |
| Shell Size, MIL | - | - | - |
| Mounting Type | Panel Mount | Panel Mount | - |
| Mounting Feature | Flange | Flange | - |
| Termination | Solder Cup | Solder Cup | - |
| Fastening Type | Snap-In | Snap-In | - |
| Orientation | Keyed | Keyed | - |
| Primary Material | Plastic | Plastic | - |
| Shell Material | Polyamide (PA), Nylon | Polyamide (PA), Nylon | - |
| Shell Finish | - | - | - |
| Contact Finish - Mating | - | Silver | - |
| Color | Blue | Blue | - |
| Ingress Protection | - | - | - |
| Material Flammability Rating | - | - | - |
| Features | - | - | - |
| Shielding | Unshielded | Unshielded | - |
| Current Rating (Amps) | 5A | 5A | - |
| Voltage Rating | 500VAC | 500VAC | - |
| Cable Opening | 0.472" (12.00mm) | 0.472" (12.00mm) | - |
| Operating Temperature | -10°C ~ 60°C | -10°C ~ 60°C | - |
