RM15TRD-10S(71)
  • Share:

Hirose Electric Co Ltd RM15TRD-10S(71)

Manufacturer No:
RM15TRD-10S(71)
Manufacturer:
Hirose Electric Co Ltd
Package:
Bulk
Datasheet:
RM15TRD-10S(71) Datasheet
ECAD Model:
-
Description:
CONN RCPT FMALE 10P SOLDER CUP
Delivery:
Payment:
iso14001
iso45001
iso9001
iso13485

Product Attributes

Connector Type:Receptacle, Female Sockets
Number of Positions:10
Shell Size - Insert:15
Shell Size, MIL:-
Mounting Type:Panel Mount
Mounting Feature:Bulkhead - Rear Side Nut
Termination:Solder Cup
Fastening Type:Threaded
Orientation:Keyed
Primary Material:Metal
Shell Material:Zinc Alloy
Shell Finish:Chrome
Contact Finish - Mating:Silver
Color:Silver
Ingress Protection:-
Material Flammability Rating:UL94 V-0
Features:-
Shielding:-
Current Rating (Amps):5A
Voltage Rating:350VAC, 490VDC
Cable Opening:-
Operating Temperature:-25°C ~ 85°C
0 Remaining View Similar

In Stock

-
563

Please send RFQ , we will respond immediately.

Similar Products

Part Number RM15TRD-10S(71) RM15TRD-10SB(71)   RM15TRD-12S(71)   RM15TRH-10S(71)   RM15QRD-10S(71)   RM15TJD-10S(71)   RM15TPD-10S(71)   RM15TRD-10P(71)
Manufacturer Hirose Electric Co Ltd Hirose Electric Co Ltd Hirose Electric Co Ltd Hirose Electric Co Ltd Hirose Electric Co Ltd Hirose Electric Co Ltd Hirose Electric Co Ltd Hirose Electric Co Ltd
Product Status Obsolete Active Obsolete Obsolete Obsolete Obsolete Obsolete Obsolete
Connector Type Receptacle, Female Sockets Receptacle, Female Sockets Receptacle, Female Sockets Receptacle, Female Sockets Receptacle, Female Sockets Jack, Female Sockets Plug, Female Sockets Receptacle, Male Pins
Number of Positions 10 10 12 10 10 10 10 10
Shell Size - Insert 15 15 15 15 15 15 15 15
Shell Size, MIL - - - - - - - -
Mounting Type Panel Mount Panel Mount, Through Hole Panel Mount Panel Mount Panel Mount Free Hanging (In-Line) Free Hanging (In-Line) Panel Mount
Mounting Feature Bulkhead - Rear Side Nut Bulkhead - Rear Side Nut Bulkhead - Rear Side Nut Bulkhead - Rear Side Nut Bulkhead - Rear Side Nut - - Bulkhead - Rear Side Nut
Termination Solder Cup Solder Solder Cup Solder Cup Solder Cup Solder Cup Solder Cup Solder Cup
Fastening Type Threaded Threaded Threaded Threaded Push-Twist Threaded Threaded Threaded
Orientation Keyed Keyed Keyed Keyed Keyed Keyed Keyed Keyed
Primary Material Metal Metal Metal Metal Metal Metal Metal Metal
Shell Material Zinc Alloy Zinc Alloy Zinc Alloy Brass Brass Zinc Alloy Zinc Alloy Zinc Alloy
Shell Finish Chrome Chrome Chrome Nickel Nickel Chrome Chrome Chrome
Contact Finish - Mating Silver Silver Silver Silver Silver Silver Silver Silver
Color Silver Silver Silver Silver Silver Silver Silver Silver
Ingress Protection - - - - - - - -
Material Flammability Rating UL94 V-0 UL94 V-0 UL94 V-0 UL94 V-0 UL94 V-0 UL94 V-0 UL94 V-0 UL94 V-0
Features - - - - - Backshell, Cable Clamp, Strain Relief Backshell, Cable Clamp, Coupling Nut, Strain Relief -
Shielding - - - - - - - -
Current Rating (Amps) 5A 5A 5A 5A 5A 5A 5A 5A
Voltage Rating 350VAC, 490VDC 350VAC, 490VDC 350VAC, 490VDC 350VAC, 490VDC 350VAC, 490VDC 350VAC, 490VDC 350VAC, 490VDC 350VAC, 490VDC
Cable Opening - - - - - 0.386" (9.80mm) 0.386" (9.80mm) -
Operating Temperature -25°C ~ 85°C -25°C ~ 85°C -25°C ~ 85°C -25°C ~ 85°C -25°C ~ 85°C -25°C ~ 85°C -25°C ~ 85°C -25°C ~ 85°C
