MDF7-25P-2.54DSA(37)
  • Share:

Hirose Electric Co Ltd MDF7-25P-2.54DSA(37)

Manufacturer No:
MDF7-25P-2.54DSA(37)
Manufacturer:
Hirose Electric Co Ltd
Package:
Bulk
Datasheet:
MDF7-25P-2.54DSA(37) Datasheet
ECAD Model:
-
Description:
CONN HEADER VERT 25POS 2.54MM
Delivery:
Payment:
iso14001
iso45001
iso9001
iso13485

Product Attributes

Connector Type:Header
Contact Type:Male Pin
Pitch - Mating:0.100" (2.54mm)
Number of Positions:25
Number of Rows:1
Row Spacing - Mating:-
Number of Positions Loaded:18
Style:Board to Board
Shrouding:Unshrouded
Mounting Type:Through Hole
Termination:Solder
Fastening Type:Push-Pull
Contact Length - Mating:0.394" (10.00mm)
Contact Length - Post:0.118" (3.00mm)
Overall Contact Length:0.612" (15.54mm)
Insulation Height:0.100" (2.54mm)
Contact Shape:Square
Contact Finish - Mating:Gold
Contact Finish Thickness - Mating:8.00µin (0.203µm)
Contact Finish - Post:-
Contact Material:Brass
Insulation Material:Polybutylene Terephthalate (PBT)
Features:-
Operating Temperature:-35°C ~ 85°C
Ingress Protection:-
Material Flammability Rating:UL94 V-0
Insulation Color:Black
Current Rating (Amps):3A
Voltage Rating:250V
0 Remaining View Similar

In Stock

-
170

Please send RFQ , we will respond immediately.
