| Part Number | JR25WR-4S(71) | JR25WR-5S(71) | JR25WR-8S(71) | JR25WP-4S(71) | JR25WR-24S(71) | JR25WR-4P(71) |
|---|---|---|---|---|---|---|
| Manufacturer | Hirose Electric Co Ltd | Hirose Electric Co Ltd | Hirose Electric Co Ltd | Hirose Electric Co Ltd | Hirose Electric Co Ltd | Hirose Electric Co Ltd |
| Product Status | Obsolete | Obsolete | Obsolete | Obsolete | Obsolete | Obsolete |
| Connector Type | - | - | - | - | Receptacle, Female Sockets | - |
| Number of Positions | - | - | - | - | 24 | - |
| Shell Size - Insert | - | - | - | - | 25 | - |
| Shell Size, MIL | - | - | - | - | - | - |
| Mounting Type | - | - | - | - | Panel Mount | - |
| Mounting Feature | - | - | - | - | Flange | - |
| Termination | - | - | - | - | Solder Cup | - |
| Fastening Type | - | - | - | - | Threaded | - |
| Orientation | - | - | - | - | Keyed | - |
| Primary Material | - | - | - | - | Metal | - |
| Shell Material | - | - | - | - | Aluminum Alloy | - |
| Shell Finish | - | - | - | - | Black Chromium | - |
| Contact Finish - Mating | - | - | - | - | Silver | - |
| Color | - | - | - | - | Black | - |
| Ingress Protection | - | - | - | - | IP67/IP68 - Dust Tight, Waterproof | - |
| Material Flammability Rating | - | - | - | - | UL94 V-0 | - |
| Features | - | - | - | - | - | - |
| Shielding | - | - | - | - | - | - |
| Current Rating (Amps) | - | - | - | - | 5A | - |
| Voltage Rating | - | - | - | - | 100VAC, 140VDC | - |
| Cable Opening | - | - | - | - | 1.098" (27.90mm) | - |
| Operating Temperature | - | - | - | - | -25°C ~ 85°C | - |
