| Part Number | HV-R-SR2(12) | HV-LR-SR2(12) | HV-R-SR2(11) |
|---|---|---|---|
| Manufacturer | Hirose Electric Co Ltd | Hirose Electric Co Ltd | Hirose Electric Co Ltd |
| Product Status | Active | Active | Active |
| Connector Style | 1.85mm | 1.85mm | 1.85mm |
| Connector Type | Jack, Female Socket | Receptacle, Female Socket | Jack, Female Socket |
| Contact Termination | Compression | Solder | Compression |
| Shield Termination | Screw | Solder | Screw |
| Impedance | 50Ohm | 50Ohm | 50Ohm |
| Mounting Type | Panel Mount | Panel Mount, Right Angle | Panel Mount |
| Mounting Feature | Flange | - | Flange |
| Cable Group | - | - | - |
| Fastening Type | Threaded | Threaded | Threaded |
| Frequency - Max | 65 GHz | 65 GHz | 65 GHz |
| Number of Ports | 1 | 1 | 1 |
| Features | - | - | - |
| Housing Color | Silver | Gold | Silver |
| Ingress Protection | - | - | - |
| Center Contact Material | Beryllium Copper | Beryllium Copper | Beryllium Copper |
