HR10A-10R-12P
  • Share:

Hirose Electric Co Ltd HR10A-10R-12P

Manufacturer No:
HR10A-10R-12P
Manufacturer:
Hirose Electric Co Ltd
Package:
Bulk
Datasheet:
HR10A-10R-12P Datasheet
ECAD Model:
-
Description:
CONN RCPT MALE 12 POS
Delivery:
Payment:
iso14001
iso45001
iso9001
iso13485

Product Attributes

Connector Type:Receptacle, Male Pins
Number of Positions:12
Shell Size - Insert:10
Shell Size, MIL:-
Mounting Type:Panel Mount
Mounting Feature:Bulkhead - Rear Side Nut
Termination:-
Fastening Type:Push-Pull
Orientation:Keyed
Primary Material:-
Shell Material:-
Shell Finish:-
Contact Finish - Mating:-
Color:-
Ingress Protection:-
Material Flammability Rating:-
Features:-
Shielding:Unshielded
Current Rating (Amps):2A
Voltage Rating:100VAC, 140VDC
Cable Opening:-
Operating Temperature:-25°C ~ 85°C
0 Remaining View Similar

In Stock

-
12

Please send RFQ , we will respond immediately.

Similar Products

Part Number HR10A-10R-12P HR10A-10R-12S   HR10A-10R-12PB   HR10-10R-12P   HR10A-10J-12P   HR10A-10P-12P   HR10A-10R-10P
Manufacturer Hirose Electric Co Ltd Hirose Electric Co Ltd Hirose Electric Co Ltd Hirose Electric Co Ltd Hirose Electric Co Ltd Hirose Electric Co Ltd Hirose Electric Co Ltd
Product Status Obsolete Obsolete Obsolete Obsolete Obsolete Obsolete Obsolete
Connector Type Receptacle, Male Pins Receptacle, Female Sockets Receptacle, Male Pins Receptacle, Male Pins Jack, Male Pins Plug, Male Pins Receptacle, Male Pins
Number of Positions 12 12 12 12 12 12 10
Shell Size - Insert 10 10 10 10 10 10 10
Shell Size, MIL - - - - - - -
Mounting Type Panel Mount Panel Mount Panel Mount, Through Hole Panel Mount Free Hanging (In-Line) Free Hanging (In-Line) Panel Mount
Mounting Feature Bulkhead - Rear Side Nut Bulkhead - Rear Side Nut Bulkhead - Rear Side Nut Bulkhead - Rear Side Nut - - Bulkhead - Rear Side Nut
Termination - - - Solder Cup - - -
Fastening Type Push-Pull Push-Pull Push-Pull Push-Pull Push-Pull Push-Pull Push-Pull
Orientation Keyed Keyed Keyed Keyed Keyed Keyed Keyed
Primary Material - - - Metal - - -
Shell Material - - - - - - -
Shell Finish - - - Nickel - - -
Contact Finish - Mating - - - Gold - - -
Color - - - - - - -
Ingress Protection - - - - - - -
Material Flammability Rating - - - - - - -
Features - - - - - - -
Shielding Unshielded Unshielded Unshielded Unshielded Unshielded Unshielded Unshielded
Current Rating (Amps) 2A 2A 2A 2A 2A 2A 2A
Voltage Rating 100VAC, 140VDC 100VAC, 140VDC 100VAC, 140VDC 100VAC, 140VDC 100VAC, 140VDC 100VAC, 140VDC 100VAC, 140VDC
Cable Opening - - - - - - -
Operating Temperature -25°C ~ 85°C -25°C ~ 85°C -25°C ~ 85°C -25°C ~ 85°C -25°C ~ 85°C -25°C ~ 85°C -25°C ~ 85°C
