GT8E-16DP-2H(55)
  • Share:

Hirose Electric Co Ltd GT8E-16DP-2H(55)

Manufacturer No:
GT8E-16DP-2H(55)
Manufacturer:
Hirose Electric Co Ltd
Package:
Tape & Reel (TR)
Datasheet:
GT8E-16DP-2H(55) Datasheet
ECAD Model:
-
Description:
CONN HEADER SMD R/A 16POS 2MM
Delivery:
Payment:
iso14001
iso45001
iso9001
iso13485

Product Attributes

Connector Type:Header
Contact Type:Male Pin
Pitch - Mating:0.079" (2.00mm)
Number of Positions:16
Number of Rows:2
Row Spacing - Mating:0.079" (2.00mm)
Number of Positions Loaded:All
Style:Board to Cable/Wire
Shrouding:Shrouded - 4 Wall
Mounting Type:Surface Mount, Right Angle
Termination:Solder
Fastening Type:Latch Holder
Contact Length - Mating:-
Contact Length - Post:-
Overall Contact Length:-
Insulation Height:0.403" (10.23mm)
Contact Shape:Square
Contact Finish - Mating:Tin
Contact Finish Thickness - Mating:-
Contact Finish - Post:Tin
Contact Material:Brass
Insulation Material:Polyphenylene Sulfide (PPS)
Features:Solder Retention
Operating Temperature:-40°C ~ 105°C
Ingress Protection:-
Material Flammability Rating:-
Insulation Color:Black
Current Rating (Amps):1A
Voltage Rating:250VAC
0 Remaining View Similar

In Stock

$3.02
171

Please send RFQ , we will respond immediately.

Similar Products

Part Number GT8E-16DP-2H(55) GT8E-12DP-2H(55)
Manufacturer Hirose Electric Co Ltd Hirose Electric Co Ltd
Product Status Active Active
Connector Type Header Header
Contact Type Male Pin Male Pin
Pitch - Mating 0.079" (2.00mm) 0.079" (2.00mm)
Number of Positions 16 12
Number of Rows 2 2
Row Spacing - Mating 0.079" (2.00mm) 0.079" (2.00mm)
Number of Positions Loaded All All
Style Board to Cable/Wire Board to Cable/Wire
Shrouding Shrouded - 4 Wall Shrouded - 4 Wall
Mounting Type Surface Mount, Right Angle Surface Mount, Right Angle
Termination Solder Solder
Fastening Type Latch Holder Latch Holder
Contact Length - Mating - -
Contact Length - Post - -
Overall Contact Length - -
Insulation Height 0.403" (10.23mm) 0.403" (10.23mm)
Contact Shape Square Square
Contact Finish - Mating Tin Tin
Contact Finish Thickness - Mating - -
Contact Finish - Post Tin Tin
Contact Material Brass Brass
Insulation Material Polyphenylene Sulfide (PPS) Polyphenylene Sulfide (PPS)
Features Solder Retention Solder Retention
Operating Temperature -40°C ~ 105°C -40°C ~ 105°C
Ingress Protection - -
Material Flammability Rating - -
Insulation Color Black Black
Current Rating (Amps) 1A 1A
Voltage Rating 250VAC 250VAC
