| Part Number | FX2-60S-1.27DSL(71) | FX2-68S-1.27DSL(71) | FX2-80S-1.27DSL(71) | FX2-20S-1.27DSL(71) | FX2-40S-1.27DSL(71) | FX2-60P-1.27DSL(71) | FX2-60S-1.27DS(71) |
|---|---|---|---|---|---|---|---|
| Manufacturer | Hirose Electric Co Ltd | Hirose Electric Co Ltd | Hirose Electric Co Ltd | Hirose Electric Co Ltd | Hirose Electric Co Ltd | Hirose Electric Co Ltd | Hirose Electric Co Ltd |
| Product Status | Active | Active | Active | Active | Active | Active | Active |
| Connector Style | Outer Shroud Contacts | Outer Shroud Contacts | Outer Shroud Contacts | Outer Shroud Contacts | Outer Shroud Contacts | Center Strip Contacts | Outer Shroud Contacts |
| Connector Type | Receptacle | Receptacle | Receptacle | Receptacle | Receptacle | Plug | Receptacle |
| Number of Positions | 60 | 68 | 80 | 20 | 40 | 60 | 60 |
| Number of Rows | 2 | 2 | 2 | 2 | 2 | 2 | 2 |
| Mounting Type | Through Hole, Right Angle | Through Hole, Right Angle | Through Hole, Right Angle | Through Hole, Right Angle | Through Hole, Right Angle | Through Hole, Right Angle | Through Hole, Right Angle |
| Termination | Solder | Solder | Solder | Solder | Solder | Solder | Solder |
| Flange Feature | - | - | - | - | - | - | - |
| Type | Board to Board | Board to Board | Board to Board | Board to Board | Board to Board | Board to Board | Board to Board |
| Features | Board Lock | Board Lock | Board Lock | Board Lock | Board Lock | Board Lock | - |
| Contact Finish | Gold | Gold | Gold | Gold | Gold | Gold | Gold |
| Contact Finish Thickness | 7.87µin (0.200µm) | 7.87µin (0.200µm) | 7.87µin (0.200µm) | - | 7.87µin (0.200µm) | 7.87µin (0.200µm) | 7.87µin (0.200µm) |
