| Part Number | DX30A-20P(50) | DX30A-28P(50) | DX30A-50P(50) | DX31A-20P(50) | DX30A-80P(50) |
|---|---|---|---|---|---|
| Manufacturer | Hirose Electric Co Ltd | Hirose Electric Co Ltd | Hirose Electric Co Ltd | Hirose Electric Co Ltd | Hirose Electric Co Ltd |
| Product Status | Active | Active | Active | Active | Active |
| Connector Style | Center Strip Contacts | Center Strip Contacts | Center Strip Contacts | Center Strip Contacts | Center Strip Contacts |
| Connector Type | Plug | Plug | Plug | Plug | Plug |
| Number of Positions | 20 | 28 | 50 | 20 | 80 |
| Number of Rows | 2 | 2 | 2 | 2 | 2 |
| Mounting Type | Free Hanging (In-Line) | Free Hanging (In-Line) | Free Hanging (In-Line) | Free Hanging (In-Line) | Free Hanging (In-Line) |
| Termination | IDC | IDC | IDC | IDC | IDC |
| Flange Feature | Mating Side (M2.6); Latchblocks | Mating Side (M2.6); Latchblocks | Mating Side (M2.6); Latchblocks | Mating Side (M2.6); Latchblocks | Mating Side (M2.6); Latchblocks |
| Type | Miniature High Density (HD) | Miniature High Density (HD) | Miniature High Density (HD) | Miniature High Density (HD) | Miniature High Density (HD) |
| Features | - | - | - | - | - |
| Contact Finish | Gold | Gold | Gold | Gold | Gold |
| Contact Finish Thickness | 7.87µin (0.200µm) | 7.87µin (0.200µm) | 7.87µin (0.200µm) | 7.87µin (0.200µm) | 7.87µin (0.200µm) |
