DF13E-30DP-1.25V(82)
  • Share:

Hirose Electric Co Ltd DF13E-30DP-1.25V(82)

Manufacturer No:
DF13E-30DP-1.25V(82)
Manufacturer:
Hirose Electric Co Ltd
Package:
Tape & Reel (TR)
Datasheet:
DF13E-30DP-1.25V(82) Datasheet
ECAD Model:
-
Description:
CONN HEADER SMD 30POS 1.25MM
Delivery:
Payment:
iso14001
iso45001
iso9001
iso13485

Product Attributes

Connector Type:Header
Contact Type:Male Pin
Pitch - Mating:0.049" (1.25mm)
Number of Positions:30
Number of Rows:2
Row Spacing - Mating:0.049" (1.25mm)
Number of Positions Loaded:All
Style:Board to Cable/Wire
Shrouding:Shrouded - 4 Wall
Mounting Type:Surface Mount
Termination:Solder
Fastening Type:Push-Pull
Contact Length - Mating:0.094" (2.40mm)
Contact Length - Post:-
Overall Contact Length:-
Insulation Height:0.189" (4.80mm)
Contact Shape:Square
Contact Finish - Mating:Gold
Contact Finish Thickness - Mating:30.0µin (0.76µm)
Contact Finish - Post:Tin-Copper
Contact Material:Brass
Insulation Material:Polyamide (PA), Nylon
Features:Board Guide, Solder Retention
Operating Temperature:-35°C ~ 85°C
Ingress Protection:-
Material Flammability Rating:UL94 V-0
Insulation Color:Beige
Current Rating (Amps):1A
Voltage Rating:150V
0 Remaining View Similar

In Stock

-
274

Please send RFQ , we will respond immediately.

Similar Products

Part Number DF13E-30DP-1.25V(82) DF13E-40DP-1.25V(82)
Manufacturer Hirose Electric Co Ltd Hirose Electric Co Ltd
Product Status Obsolete Obsolete
Connector Type Header Header
Contact Type Male Pin Male Pin
Pitch - Mating 0.049" (1.25mm) 0.049" (1.25mm)
Number of Positions 30 40
Number of Rows 2 2
Row Spacing - Mating 0.049" (1.25mm) 0.049" (1.25mm)
Number of Positions Loaded All All
Style Board to Cable/Wire Board to Cable/Wire
Shrouding Shrouded - 4 Wall Shrouded - 4 Wall
Mounting Type Surface Mount Surface Mount
Termination Solder Solder
Fastening Type Push-Pull Push-Pull
Contact Length - Mating 0.094" (2.40mm) 0.094" (2.40mm)
Contact Length - Post - -
Overall Contact Length - -
Insulation Height 0.189" (4.80mm) 0.189" (4.80mm)
Contact Shape Square Square
Contact Finish - Mating Gold Gold
Contact Finish Thickness - Mating 30.0µin (0.76µm) 30.0µin (0.76µm)
Contact Finish - Post Tin-Copper Tin-Copper
Contact Material Brass Brass
Insulation Material Polyamide (PA), Nylon Polyamide (PA), Nylon
Features Board Guide, Solder Retention Board Guide, Solder Retention
Operating Temperature -35°C ~ 85°C -35°C ~ 85°C
Ingress Protection - -
Material Flammability Rating UL94 V-0 UL94 V-0
Insulation Color Beige Beige
Current Rating (Amps) 1A 1A
Voltage Rating 150V 150V
