| Part Number | AT-110(40) | AT-510(40) | AT-410(40) | AT-113(40) | AT-115(40) | AT-120(40) | AT-130(40) | AT-112(40) | AT-310(40) | AT-210(40) | AT-1103(40) | AT-1106(40) | AT-1110(40) | AT-1120(40) | AT-114(40) | AT-1910(40) | AT-610(40) | AT-1010(40) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Manufacturer | Hirose Electric Co Ltd | Hirose Electric Co Ltd | Hirose Electric Co Ltd | Hirose Electric Co Ltd | Hirose Electric Co Ltd | Hirose Electric Co Ltd | Hirose Electric Co Ltd | Hirose Electric Co Ltd | Hirose Electric Co Ltd | Hirose Electric Co Ltd | Hirose Electric Co Ltd | Hirose Electric Co Ltd | Hirose Electric Co Ltd | Hirose Electric Co Ltd | Hirose Electric Co Ltd | Hirose Electric Co Ltd | Hirose Electric Co Ltd | Hirose Electric Co Ltd |
| Product Status | Active | Active | Active | Active | Active | Active | Active | Active | Active | Active | Active | Active | Active | Active | Last Time Buy | Last Time Buy | Obsolete | Active |
| Attenuation Value | 10dB | 10dB | 10dB | 13dB | 15dB | 20dB | 30dB | 12dB | 10dB | 10dB | 3dB | 6dB | 10dB | 20dB | 14dB | 10dB | 10dB | 10dB |
| Frequency Range | 0 Hz ~ 18 GHz | 0 Hz ~ 4 GHz | 0 Hz ~ 13 GHz | 0 Hz ~ 18 GHz | 0 Hz ~ 18 GHz | 0 Hz ~ 18 GHz | 0 Hz ~ 18 GHz | 0 Hz ~ 18 GHz | 0 Hz ~ 18 GHz | 0 Hz ~ 18 GHz | 0 Hz ~ 8 GHz | 0 Hz ~ 8 GHz | 0 Hz ~ 8 GHz | 0 Hz ~ 8 GHz | 0 Hz ~ 18 GHz | 0 Hz ~ 8 GHz | 0 Hz ~ 6 GHz | 0 Hz ~ 8 GHz |
| Power (Watts) | 1W | 2W | 2W | 1W | 1W | 1W | 1W | 1W | 1W | 1W | 10W | 10W | 10W | 10W | 1W | 2W | 2W | 10W |
| Impedance | 50 Ohms | 50 Ohms | 50 Ohms | 50 Ohms | 50 Ohms | 50 Ohms | 50 Ohms | 50 Ohms | 50 Ohms | 50 Ohms | 50 Ohms | 50 Ohms | 50 Ohms | 50 Ohms | 50 Ohms | 50 Ohms | 50 Ohms | 50 Ohms |
| Package / Case | SMA In-Line Module | BNC In-Line Module | N-Type In-Line Module | SMA In-Line Module | SMA In-Line Module | SMA In-Line Module | SMA In-Line Module | SMA In-Line Module | SMA In-Line Module | SMA In-Line Module | SMA In-Line Module | SMA In-Line Module | SMA In-Line Module | SMA In-Line Module | SMA In-Line Module | SMA In-Line Module | TNC In-Line Module | SMA In-Line Module |
