Please send RFQ , we will respond immediately.
| Part Number | SDT3045VCT | SDT30B45VCT |
|---|---|---|
| Manufacturer | Diodes Incorporated | Diodes Incorporated |
| Product Status | Active | Active |
| Diode Configuration | 1 Pair Common Cathode | 1 Pair Common Cathode |
| Diode Type | Schottky | Schottky |
| Voltage - DC Reverse (Vr) (Max) | 45 V | 45 V |
| Current - Average Rectified (Io) (per Diode) | 15A | 15A |
| Voltage - Forward (Vf) (Max) @ If | 500 mV @ 15 A | 550 mV @ 15 A |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) | Fast Recovery =< 500ns, > 200mA (Io) |
| Reverse Recovery Time (trr) | - | - |
| Current - Reverse Leakage @ Vr | 500 µA @ 45 V | 500 µA @ 45 V |
| Operating Temperature - Junction | -55°C ~ 150°C | -55°C ~ 150°C |
| Mounting Type | Through Hole | Through Hole |
| Package / Case | TO-220-3 | TO-220-3 |
| Supplier Device Package | TO-220-3 | TO-220-3 |
