| Part Number | PI3DPX1205AZLBEX | PI3DPX1205A1ZLBEX | PI3DPX1205AZLBE |
|---|---|---|---|
| Manufacturer | Diodes Incorporated | Diodes Incorporated | Diodes Incorporated |
| Product Status | Obsolete | Active | Obsolete |
| Type | Buffer, ReDriver | Buffer, ReDriver | Buffer, ReDriver |
| Applications | DisplayPort | DisplayPort, USB Type C | DisplayPort |
| Input | DisplayPort | DisplayPort | DisplayPort |
| Output | DisplayPort | DisplayPort | DisplayPort |
| Data Rate (Max) | 10Gbps | 10Gbps | 10Gbps |
| Number of Channels | 6 | 6 | 6 |
| Delay Time | - | - | - |
| Signal Conditioning | Input Equalization | Input Equalization | Input Equalization |
| Capacitance - Input | - | - | - |
| Voltage - Supply | 3.3V | 3.3V | 3.3V |
| Current - Supply | - | - | - |
| Operating Temperature | - | 0°C ~ 70°C | - |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount |
| Package / Case | 40-WFQFN Exposed Pad | 40-WFQFN Exposed Pad | 40-WFQFN Exposed Pad |
| Supplier Device Package | 40-TQFN (4x6) | 40-TQFN (4x6) | 40-TQFN (4x6) |
