| Part Number | PI2SSD3212NCE | PI2SSD3212NCEX |
|---|---|---|
| Manufacturer | Diodes Incorporated | Diodes Incorporated |
| Product Status | Obsolete | Active |
| Switch Circuit | SPDT | SPDT |
| Multiplexer/Demultiplexer Circuit | 2:1 | 2:1 |
| Number of Circuits | 14 | 14 |
| On-State Resistance (Max) | 8Ohm (Typ) | 8Ohm (Typ) |
| Channel-to-Channel Matching (ΔRon) | - | - |
| Voltage - Supply, Single (V+) | 1.35V, 1.5V, 1.8V | 1.35V, 1.5V, 1.8V |
| Voltage - Supply, Dual (V±) | - | - |
| Switch Time (Ton, Toff) (Max) | - | - |
| -3db Bandwidth | 3.3GHz | 3.3GHz |
| Charge Injection | - | - |
| Channel Capacitance (CS(off), CD(off)) | - | - |
| Current - Leakage (IS(off)) (Max) | - | - |
| Crosstalk | - | - |
| Operating Temperature | - | - |
| Mounting Type | Surface Mount | Surface Mount |
| Package / Case | 48-TFBGA | 48-TFBGA |
| Supplier Device Package | 48-TFBGA (4.5x4.5) | 48-TFBGA (4.5x4.5) |
