Diodes Incorporated-PAM3115CLA330 - PMIC - Voltage Regulators - Linear Product Specifications and Latest Quotes

Output Configuration:	Positive
Output Type:	Fixed
Number of Regulators:	1
Voltage - Input (Max):	3.6V
Voltage - Output (Min/Fixed):	3.3V
Voltage - Output (Max):	-
Voltage Dropout (Max):	0.3V @ 1.5A
Current - Output:	1.5A
Current - Quiescent (Iq):	150 µA
Current - Supply (Max):	600 µA
PSRR:	55dB ~ 35dB (100Hz ~ 10kHz)
Control Features:	Enable
Protection Features:	Over Current, Over Temperature, Short Circuit
Operating Temperature:	-40°C ~ 85°C
Mounting Type:	Surface Mount
Package / Case:	TO-252-3, DPak (2 Leads + Tab), SC-63
Supplier Device Package:	TO-252-3

Diodes Incorporated PAM3115CLA330
