Please send RFQ , we will respond immediately.
| Part Number | NX5AC50001 | NX5AC50003 | NX5AC50002 | NX5AC50004 | NX51C50001 | NX52C50001 | NX53C50001 |
|---|---|---|---|---|---|---|---|
| Manufacturer | Diodes Incorporated | Diodes Incorporated | Diodes Incorporated | Diodes Incorporated | Diodes Incorporated | Diodes Incorporated | Diodes Incorporated |
| Product Status | Active | Active | Active | Active | Active | Active | Active |
| Base Resonator | Crystal | Crystal | Crystal | Crystal | Crystal | Crystal | Crystal |
| Type | XO (Standard) | XO (Standard) | XO (Standard) | XO (Standard) | XO (Standard) | XO (Standard) | XO (Standard) |
| Frequency | 125 MHz | 125 MHz | 125 MHz | - | - | - | - |
| Function | Enable/Disable | Enable/Disable | Enable/Disable | - | - | - | - |
| Output | HCMOS, LVCMOS | LVCMOS | LVCMOS | - | - | - | - |
| Voltage - Supply | 3.3V | 3.3V | 3.3V | - | - | - | - |
| Frequency Stability | ±25ppm | ±25ppm | ±50ppm | - | - | - | - |
| Absolute Pull Range (APR) | - | - | - | - | - | - | - |
| Operating Temperature | -20°C ~ 70°C | -40°C ~ 85°C | -40°C ~ 85°C | - | - | - | - |
| Spread Spectrum Bandwidth | - | - | - | - | - | - | - |
| Current - Supply (Max) | 60mA | 60mA | 60mA | - | - | - | - |
| Ratings | - | - | - | - | - | - | - |
| Mounting Type | Surface Mount | Surface Mount | - | Surface Mount | - | - | - |
| Package / Case | 4-SMD, No Lead | 4-SMD, No Lead | - | 4-SMD, No Lead | - | - | - |
| Size / Dimension | 0.197" L x 0.126" W (5.00mm x 3.20mm) | 0.197" L x 0.126" W (5.00mm x 3.20mm) | - | 0.197" L x 0.126" W (5.00mm x 3.20mm) | - | - | - |
| Height - Seated (Max) | 0.053" (1.35mm) | 0.053" (1.35mm) | - | 0.053" (1.35mm) | - | - | - |
