| Part Number | MUR460D | MUR460L | MUR460G | MUR460S | MUR460H | MUR460 |
|---|---|---|---|---|---|---|
| Manufacturer | Diodes Incorporated | Diotec Semiconductor | onsemi | Taiwan Semiconductor Corporation | Taiwan Semiconductor Corporation | Taiwan Semiconductor Corporation |
| Product Status | Active | Active | Active | Active | Active | Active |
| Diode Type | Standard | Standard | Standard | Standard | Standard | Standard |
| Voltage - DC Reverse (Vr) (Max) | 600 V | 600 V | 600 V | 600 V | 600 V | 600 V |
| Current - Average Rectified (Io) | 4A | 4A | 4A | 4A | 4A | 4A |
| Voltage - Forward (Vf) (Max) @ If | 1.28 V @ 4 A | 1.35 V @ 4 A | 1.28 V @ 4 A | - | 1.28 V @ 4 A | 1.28 V @ 4 A |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) | Fast Recovery =< 500ns, > 200mA (Io) | Fast Recovery =< 500ns, > 200mA (Io) | Fast Recovery =< 500ns, > 200mA (Io) | Fast Recovery =< 500ns, > 200mA (Io) | Fast Recovery =< 500ns, > 200mA (Io) |
| Reverse Recovery Time (trr) | 50 ns | 60 ns | 75 ns | 50 ns | 50 ns | 50 ns |
| Current - Reverse Leakage @ Vr | 10 µA @ 600 V | 10 µA @ 600 V | 10 µA @ 600 V | 10 µA @ 600 V | 10 µA @ 600 V | 10 µA @ 600 V |
| Capacitance @ Vr, F | 40pF @ 4V, 1MHz | - | - | 65pF @ 4V, 1MHz | 65pF @ 4V, 1MHz | 65pF @ 4V, 1MHz |
| Mounting Type | Through Hole | Through Hole | Through Hole | Surface Mount | Through Hole | Through Hole |
| Package / Case | DO-201AD, Axial | DO-201AA, DO-27, Axial | DO-201AA, DO-27, Axial | DO-214AB, SMC | DO-201AD, Axial | DO-201AD, Axial |
| Supplier Device Package | DO-201AD | DO-201 | Axial | DO-214AB (SMC) | DO-201AD | DO-201AD |
| Operating Temperature - Junction | -55°C ~ 175°C | -50°C ~ 150°C | -65°C ~ 175°C | -55°C ~ 175°C | -55°C ~ 175°C | -55°C ~ 175°C |
