| Part Number | MMBD4448HTA-7 | MMBD4448HTW-7 | MMBD4448HTM-7 |
|---|---|---|---|
| Manufacturer | Diodes Incorporated | Diodes Incorporated | Diodes Incorporated |
| Product Status | Active | Discontinued at Digi-Key | Discontinued at Digi-Key |
| Diode Configuration | - | 3 Independent | 3 Independent |
| Diode Type | - | Standard | Standard |
| Voltage - DC Reverse (Vr) (Max) | - | 80 V | 80 V |
| Current - Average Rectified (Io) (per Diode) | - | 250mA | 250mA |
| Voltage - Forward (Vf) (Max) @ If | - | 1.25 V @ 150 mA | 1.25 V @ 150 mA |
| Speed | - | Fast Recovery =< 500ns, > 200mA (Io) | Fast Recovery =< 500ns, > 200mA (Io) |
| Reverse Recovery Time (trr) | - | 4 ns | 4 ns |
| Current - Reverse Leakage @ Vr | - | 100 nA @ 70 V | 100 nA @ 70 V |
| Operating Temperature - Junction | - | -65°C ~ 150°C | -65°C ~ 150°C |
| Mounting Type | - | Surface Mount | Surface Mount |
| Package / Case | - | 6-TSSOP, SC-88, SOT-363 | SOT-23-6 |
| Supplier Device Package | - | SOT-363 | SOT-26 |
