Diodes Incorporated-MB352 - Diodes - Bridge Rectifiers Product Specifications and Latest Quotes

Part Number	MB352	MB354	MB356	MB352W	MB152	MB252	MB351
Manufacturer	Diodes Incorporated	Diodes Incorporated	Diodes Incorporated	Diodes Incorporated	Diodes Incorporated	Diodes Incorporated	Diodes Incorporated
Product Status	Obsolete	Obsolete	Obsolete	Obsolete	Obsolete	Obsolete	Obsolete
Diode Type	Single Phase	Single Phase	Single Phase	Single Phase	Single Phase	Single Phase	Single Phase
Technology	Standard	Standard	Standard	Standard	Standard	Standard	Standard
Voltage - Peak Reverse (Max)	200 V	400 V	600 V	200 V	200 V	200 V	100 V
Current - Average Rectified (Io)	35 A	35 A	35 A	35 A	15 A	25 A	35 A
Voltage - Forward (Vf) (Max) @ If	1.2 V @ 17.5 A	1.2 V @ 17.5 A	1.2 V @ 17.5 A	1.2 V @ 17.5 A	1.1 V @ 7.5 A	1.1 V @ 12.5 A	1.2 V @ 17.5 A
Current - Reverse Leakage @ Vr	10 µA @ 100 V	10 µA @ 400 V	10 µA @ 600 V	10 µA @ 200 V	10 µA @ 200 V	10 µA @ 200 V	10 µA @ 100 V
Operating Temperature	-55°C ~ 150°C (TJ)	-55°C ~ 150°C (TJ)	-55°C ~ 150°C (TJ)	-55°C ~ 150°C (TJ)	-55°C ~ 150°C (TJ)	-55°C ~ 150°C (TJ)	-55°C ~ 150°C (TJ)
Mounting Type	QC Terminal	QC Terminal	QC Terminal	Through Hole	QC Terminal	QC Terminal	QC Terminal
Package / Case	4-Square, MB	4-Square, MB	4-Square, MB	4-Square, MB-W	4-Square, MB	4-Square, MB	4-Square, MB
Supplier Device Package	MB	MB	MB	MB-W	MB	MB	MB

Diodes Incorporated MB352

Diode Type:	Single Phase
Technology:	Standard
Voltage - Peak Reverse (Max):	200 V
Current - Average Rectified (Io):	35 A
Voltage - Forward (Vf) (Max) @ If:	1.2 V @ 17.5 A
Current - Reverse Leakage @ Vr:	10 µA @ 100 V
Operating Temperature:	-55°C ~ 150°C (TJ)
Mounting Type:	QC Terminal
Package / Case:	4-Square, MB
Supplier Device Package:	MB
