Diodes Incorporated-MB351 - Diodes - Bridge Rectifiers Product Specifications and Latest Quotes

Part Number	MB351	MB352	MB354	MB356	MB351W	MB151	MB251
Manufacturer	Diodes Incorporated	Diodes Incorporated	Diodes Incorporated	Diodes Incorporated	Micro Commercial Co	Diodes Incorporated	Diodes Incorporated
Product Status	Obsolete	Obsolete	Obsolete	Obsolete	Obsolete	Obsolete	Obsolete
Diode Type	Single Phase	Single Phase	Single Phase	Single Phase	Single Phase	Single Phase	Single Phase
Technology	Standard	Standard	Standard	Standard	Standard	Standard	Standard
Voltage - Peak Reverse (Max)	100 V	200 V	400 V	600 V	100 V	100 V	100 V
Current - Average Rectified (Io)	35 A	35 A	35 A	35 A	35 A	15 A	25 A
Voltage - Forward (Vf) (Max) @ If	1.2 V @ 17.5 A	1.2 V @ 17.5 A	1.2 V @ 17.5 A	1.2 V @ 17.5 A	1.2 V @ 17.5 A	1.1 V @ 7.5 A	1.1 V @ 12.5 A
Current - Reverse Leakage @ Vr	10 µA @ 100 V	10 µA @ 100 V	10 µA @ 400 V	10 µA @ 600 V	10 µA @ 100 V	10 µA @ 100 V	10 µA @ 50 V
Operating Temperature	-55°C ~ 150°C (TJ)	-55°C ~ 150°C (TJ)	-55°C ~ 150°C (TJ)	-55°C ~ 150°C (TJ)	-55°C ~ 150°C (TJ)	-55°C ~ 150°C (TJ)	-55°C ~ 150°C (TJ)
Mounting Type	QC Terminal	QC Terminal	QC Terminal	QC Terminal	Through Hole	QC Terminal	QC Terminal
Package / Case	4-Square, MB	4-Square, MB	4-Square, MB	4-Square, MB	4-Square, MB-35W	4-Square, MB	4-Square, MB
Supplier Device Package	MB	MB	MB	MB	MB-35W	MB	MB

Diodes Incorporated MB351

Diode Type:	Single Phase
Technology:	Standard
Voltage - Peak Reverse (Max):	100 V
Current - Average Rectified (Io):	35 A
Voltage - Forward (Vf) (Max) @ If:	1.2 V @ 17.5 A
Current - Reverse Leakage @ Vr:	10 µA @ 100 V
Operating Temperature:	-55°C ~ 150°C (TJ)
Mounting Type:	QC Terminal
Package / Case:	4-Square, MB
Supplier Device Package:	MB
