| Part Number | DT1240-08LP3810-7 | DT1240A-08LP3810-7 |
|---|---|---|
| Manufacturer | Diodes Incorporated | Diodes Incorporated |
| Product Status | Active | Active |
| Type | Steering (Rail to Rail) | Steering (Rail to Rail) |
| Unidirectional Channels | 8 | 8 |
| Bidirectional Channels | - | - |
| Voltage - Reverse Standoff (Typ) | 5.5V (Max) | 3.3V (Max) |
| Voltage - Breakdown (Min) | 6V | 5V |
| Voltage - Clamping (Max) @ Ipp | 11V | 10V |
| Current - Peak Pulse (10/1000µs) | 5.5A | 5.5A (8/20µs) |
| Power - Peak Pulse | 60W | 55W |
| Power Line Protection | Yes | No |
| Applications | DVI, HDMI, VGA, USB | DVI, HDMI, USB |
| Capacitance @ Frequency | 0.6pF @ 1MHz | 0.6pF @ 1MHz |
| Operating Temperature | -55°C ~ 85°C (TA) | -55°C ~ 85°C (TA) |
| Mounting Type | Surface Mount | Surface Mount |
| Package / Case | 9-UDFN | 9-UDFN |
| Supplier Device Package | U-DFN3810-9 (Type B) | U-DFN3810-9 (Type B) |
