Please send RFQ , we will respond immediately.
| Part Number | DSC06065 | DSC08065 | DSC04065 |
|---|---|---|---|
| Manufacturer | Diodes Incorporated | Diodes Incorporated | Diodes Incorporated |
| Product Status | Active | Active | Active |
| Diode Type | Silicon Carbide Schottky | Silicon Carbide Schottky | Silicon Carbide Schottky |
| Voltage - DC Reverse (Vr) (Max) | 650 V | 650 V | 650 V |
| Current - Average Rectified (Io) | 6A | 8A | 4A |
| Voltage - Forward (Vf) (Max) @ If | 1.7 V @ 6 A | 1.7 V @ 8 A | 1.7 V @ 4 A |
| Speed | No Recovery Time > 500mA (Io) | No Recovery Time > 500mA (Io) | No Recovery Time > 500mA (Io) |
| Reverse Recovery Time (trr) | 0 ns | 0 ns | 0 ns |
| Current - Reverse Leakage @ Vr | 200 µA @ 650 V | 230 µA @ 650 V | 170 µA @ 650 V |
| Capacitance @ Vr, F | 225pF @ 100mV, 1MHz | 295pF @ 100mV, 1MHz | 149pF @ 100mV, 1MHz |
| Mounting Type | Through Hole | Through Hole | Through Hole |
| Package / Case | TO-220-2 | TO-220-2 | TO-220-2 |
| Supplier Device Package | TO220AC (Type WX) | TO220AC (Type WX) | TO220AC (Type WX) |
| Operating Temperature - Junction | -55°C ~ 175°C | -55°C ~ 175°C | -55°C ~ 175°C |
