| Part Number | DPS1035FIA-13 | DPS1135FIA-13 |
|---|---|---|
| Manufacturer | Diodes Incorporated | Diodes Incorporated |
| Product Status | Active | Active |
| Switch Type | USB Switch | General Purpose |
| Number of Outputs | 1 | 1 |
| Ratio - Input:Output | 1:1 | 1:1 |
| Output Configuration | - | High Side |
| Output Type | - | N-Channel |
| Interface | On/Off | On/Off |
| Voltage - Load | 4.5V ~ 24V | 4.5V ~ 24V |
| Voltage - Supply (Vcc/Vdd) | - | Not Required |
| Current - Output (Max) | 3.5A | 5A |
| Rds On (Typ) | 30mOhm | 30mOhm |
| Input Type | - | Non-Inverting |
| Features | Load Discharge, Status Flag | Load Discharge, Slew Rate Controlled, Status Flag |
| Fault Protection | Over Temperature, Over Voltage, Reverse Current, UVLO | Current Limiting (Adjustable), Over Temperature, Over Voltage, Reverse Current, Short Circuit, UVLO |
| Operating Temperature | -40°C ~ 125°C (TJ) | -40°C ~ 125°C (TJ) |
| Mounting Type | Surface Mount | Surface Mount |
| Supplier Device Package | V-QFN4040-17 | V-QFN4040-17 |
| Package / Case | 17-VFQFN Exposed Pad | 17-VFQFN Exposed Pad |
