Please send RFQ , we will respond immediately.
| Part Number | DGD0636MS28-13 | DGD0636S28-13 | DGD0636M28-13 |
|---|---|---|---|
| Manufacturer | Diodes Incorporated | Diodes Incorporated | Diodes Incorporated |
| Product Status | Active | Obsolete | Active |
| Driven Configuration | Half-Bridge | Half-Bridge | - |
| Channel Type | 3-Phase | 3-Phase | - |
| Number of Drivers | 6 | 6 | - |
| Gate Type | IGBT, N-Channel MOSFET | N-Channel MOSFET | - |
| Voltage - Supply | 10V ~ 20V | 10V ~ 20V | - |
| Logic Voltage - VIL, VIH | 0.8V, 2.4V | 0.8V, 2.4V | - |
| Current - Peak Output (Source, Sink) | 200mA, 350mA | 200mA, 350mA | - |
| Input Type | Inverting | Inverting | - |
| High Side Voltage - Max (Bootstrap) | 100 V | 100 V | - |
| Rise / Fall Time (Typ) | 90ns, 35ns | 90ns, 35ns | - |
| Operating Temperature | 150°C (TJ) | -40°C ~ 150°C (TJ) | - |
| Mounting Type | Surface Mount | Surface Mount | - |
| Package / Case | 28-SOIC (0.295", 7.50mm Width) | 28-SOIC (0.295", 7.50mm Width) | - |
| Supplier Device Package | 28-SO | 28-SO | - |
