| Part Number | D5V0H1U2LP1610-7 | D5V0S1U2LP1610-7 | D8V0H1U2LP1610-7 |
|---|---|---|---|
| Manufacturer | Diodes Incorporated | Diodes Incorporated | Diodes Incorporated |
| Product Status | Active | Active | Active |
| Type | Zener | Zener | - |
| Unidirectional Channels | 1 | 1 | - |
| Bidirectional Channels | - | - | - |
| Voltage - Reverse Standoff (Typ) | 5V (Max) | 5V (Max) | - |
| Voltage - Breakdown (Min) | 5.5V | 6V | - |
| Voltage - Clamping (Max) @ Ipp | 11.5V | 11.5V | - |
| Current - Peak Pulse (10/1000µs) | 90A (8/20µs) | 150A | - |
| Power - Peak Pulse | - | - | - |
| Power Line Protection | No | No | - |
| Applications | - | General Purpose | - |
| Capacitance @ Frequency | 800pF @ 1MHz | 800pF @ 1MHz | - |
| Operating Temperature | -55°C ~ 150°C (TJ) | -55°C ~ 150°C (TJ) | - |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount |
| Package / Case | 0603 (1610 Metric) | 0603 (1610 Metric) | 0603 (1610 Metric) |
| Supplier Device Package | U-DFN1610-2 (Type B) | U-DFN1610-2 (Type B) | U-DFN1610-2 (Type B) |
