| Part Number | D3V3X8U9LP3810-7 | D3V3F8U9LP3810-7 |
|---|---|---|
| Manufacturer | Diodes Incorporated | Diodes Incorporated |
| Product Status | Active | Active |
| Type | Zener | Zener |
| Unidirectional Channels | 8 | 8 |
| Bidirectional Channels | - | - |
| Voltage - Reverse Standoff (Typ) | 3.3V (Max) | 3.3V (Max) |
| Voltage - Breakdown (Min) | 5.5V | 5.5V |
| Voltage - Clamping (Max) @ Ipp | 7V (Typ) | 5V (Typ) |
| Current - Peak Pulse (10/1000µs) | 3A (8/20µs) | 5A (8/20µs) |
| Power - Peak Pulse | 20W | 32W |
| Power Line Protection | No | No |
| Applications | General Purpose | General Purpose |
| Capacitance @ Frequency | 0.45pF @ 1MHz | 0.55pF @ 1MHz |
| Operating Temperature | -55°C ~ 85°C (TA) | -55°C ~ 85°C (TA) |
| Mounting Type | Surface Mount | Surface Mount |
| Package / Case | 9-UDFN | 9-UDFN |
| Supplier Device Package | U-DFN3810-9 (Type B) | U-DFN3810-9 (Type B) |
