| Part Number | D26V0H1U2LP20-7 | D26V0S1U2LP20-7 |
|---|---|---|
| Manufacturer | Diodes Incorporated | Diodes Incorporated |
| Product Status | Active | Active |
| Type | Zener | Zener |
| Unidirectional Channels | 1 | 1 |
| Bidirectional Channels | - | - |
| Voltage - Reverse Standoff (Typ) | 26V (Max) | 26V (Max) |
| Voltage - Breakdown (Min) | 28V | 28V |
| Voltage - Clamping (Max) @ Ipp | 40V | 44V |
| Current - Peak Pulse (10/1000µs) | 9.5A | 110A (8/20µs) |
| Power - Peak Pulse | 300W | 4800W (4.8kW) |
| Power Line Protection | No | No |
| Applications | General Purpose | General Purpose |
| Capacitance @ Frequency | 630pF @ 1MHz | 630pF @ 1MHz |
| Operating Temperature | -65°C ~ 150°C (TJ) | -65°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount | Surface Mount |
| Package / Case | 2-UDFN | 2-UDFN |
| Supplier Device Package | U-DFN2020-2 | U-DFN2020-2 |
