| Part Number | D15V0S1U2LP1608-7 | D15V0S1U2LP1608A-7 | D12V0S1U2LP1608-7 |
|---|---|---|---|
| Manufacturer | Diodes Incorporated | Diodes Incorporated | Diodes Incorporated |
| Product Status | Active | Active | Active |
| Type | Zener | Zener | Zener |
| Unidirectional Channels | 1 | 1 | 1 |
| Bidirectional Channels | - | - | - |
| Voltage - Reverse Standoff (Typ) | 15V | 15V | 12V |
| Voltage - Breakdown (Min) | 17V | 17V | 13V |
| Voltage - Clamping (Max) @ Ipp | 30V | 35V | 22V |
| Current - Peak Pulse (10/1000µs) | 35A | 40A | 55A |
| Power - Peak Pulse | - | - | - |
| Power Line Protection | No | No | No |
| Applications | General Purpose | General Purpose | General Purpose |
| Capacitance @ Frequency | 264pF @ 1MHz | 264pF @ 1MHz | 380pF @ 1MHz |
| Operating Temperature | -55°C ~ 150°C (TJ) | -55°C ~ 150°C (TJ) | -55°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount |
| Package / Case | 2-UFDFN | 2-UFDFN | 2-UFDFN |
| Supplier Device Package | U-DFN1608-2 | U-DFN1608-2 | U-DFN1608-2 |
