| Part Number | BPSS00080740820T00 | BPSS00080740220T00 | BPSS00080740820M00 |
|---|---|---|---|
| Manufacturer | Chilisin Electronics | Chilisin Electronics | Chilisin Electronics |
| Product Status | Active | Active | Active |
| Type | - | - | - |
| Material - Core | - | - | - |
| Inductance | 82 µH | 22 µH | 82 µH |
| Tolerance | ±30% | ±30% | ±20% |
| Current Rating (Amps) | 1.12 A | 2.4 A | 1.12 A |
| Current - Saturation (Isat) | 1.2A | 2.4A | 1.2A |
| Shielding | Shielded | Shielded | Shielded |
| DC Resistance (DCR) | 360mOhm Max | 98.1mOhm Max | 360mOhm Max |
| Q @ Freq | - | - | - |
| Frequency - Self Resonant | - | - | - |
| Ratings | - | - | - |
| Operating Temperature | -40°C ~ 105°C | -40°C ~ 105°C | -40°C ~ 105°C |
| Inductance Frequency - Test | 100 kHz | 100 kHz | 100 kHz |
| Features | - | - | - |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount |
| Package / Case | Nonstandard | Nonstandard | Nonstandard |
| Supplier Device Package | - | - | - |
| Size / Dimension | 0.362" L x 0.291" W (9.20mm x 7.40mm) | 0.362" L x 0.291" W (9.20mm x 7.40mm) | 0.362" L x 0.291" W (9.20mm x 7.40mm) |
| Height - Seated (Max) | 0.157" (4.00mm) | 0.157" (4.00mm) | 0.157" (4.00mm) |
