| Part Number | APSA00070748680M00 | APSA00070748681M00 |
|---|---|---|
| Manufacturer | Chilisin Electronics | Pulse Electronics Power |
| Product Status | Active | Active |
| Type | Drum Core, Wirewound | Drum Core, Wirewound |
| Material - Core | Ferrite | Ferrite |
| Inductance | 68 µH | 680 µH |
| Tolerance | ±20% | ±20% |
| Current Rating (Amps) | 770 mA | 270 mA |
| Current - Saturation (Isat) | 600mA | 200mA |
| Shielding | Shielded | Shielded |
| DC Resistance (DCR) | 210mOhm Max | 1.77Ohm Max |
| Q @ Freq | - | - |
| Frequency - Self Resonant | - | 2.1MHz |
| Ratings | AEC-Q200 | AEC-Q200 |
| Operating Temperature | -40°C ~ 125°C | -40°C ~ 125°C |
| Inductance Frequency - Test | 100 kHz | 100 kHz |
| Features | - | - |
| Mounting Type | Surface Mount | Surface Mount |
| Package / Case | Nonstandard | Nonstandard |
| Supplier Device Package | - | - |
| Size / Dimension | 0.287" L x 0.287" W (7.30mm x 7.30mm) | 0.287" L x 0.287" W (7.30mm x 7.30mm) |
| Height - Seated (Max) | 0.189" (4.80mm) | 0.189" (4.80mm) |
