| Part Number | APMI0004044022NM0J | APMI0004044022NT0J |
|---|---|---|
| Manufacturer | Chilisin Electronics | Chilisin Electronics |
| Product Status | Active | Active |
| Type | - | - |
| Material - Core | Ferrite | Ferrite |
| Inductance | 22 nH | 22 nH |
| Tolerance | ±20% | ±30% |
| Current Rating (Amps) | 28 A | 28 A |
| Current - Saturation (Isat) | 60A | 60A |
| Shielding | Shielded | Shielded |
| DC Resistance (DCR) | 0.23mOhm | 0.23mOhm |
| Q @ Freq | - | - |
| Frequency - Self Resonant | - | - |
| Ratings | AEC-Q200 | AEC-Q200 |
| Operating Temperature | -40°C ~ 125°C | -40°C ~ 125°C |
| Inductance Frequency - Test | 100 kHz | 100 kHz |
| Features | - | - |
| Mounting Type | Surface Mount | Surface Mount |
| Package / Case | Nonstandard | Nonstandard |
| Supplier Device Package | - | - |
| Size / Dimension | 0.165" L x 0.157" W (4.20mm x 4.00mm) | 0.165" L x 0.157" W (4.20mm x 4.00mm) |
| Height - Seated (Max) | 0.157" (4.00mm) | 0.157" (4.00mm) |
