AFDI00303012220M04
AFDI00303012220M04 Image
×
Favorite
Compare
Add to RFQ
Share:
Chilisin Electronics AFDI00303012220M04
Manufacturer No:
AFDI00303012220M04
Manufacturer:
Chilisin Electronics
Package:
Tape & Reel (TR)
Datasheet:
AFDI00303012220M04 Datasheet
ECAD Model:
-
Description:
INDUCTOR CHOKE
Delivery:
Payment:
Product Attributes
Type:
Drum Core, Wirewound
Material - Core:
Metal
Inductance:
22 µH
Tolerance:
±20%
Current Rating (Amps):
23 A
Current - Saturation (Isat):
23A
Shielding:
Shielded
DC Resistance (DCR):
6.83mOhm Max
Q @ Freq:
-
Frequency - Self Resonant:
-
Ratings:
AEC-Q200
Operating Temperature:
-50°C ~ 155°C
Inductance Frequency - Test:
100 kHz
Features:
-
Mounting Type:
Through Hole
Package / Case:
Radial
Supplier Device Package:
Radial
Size / Dimension:
1.181" L x 1.181" W (30.00mm x 30.00mm)
Height - Seated (Max):
0.500" (12.70mm)
0
Remaining
View Similar
In Stock
UnitPrice:
$3.92
Quantity:
210
