| Part Number | AFDI002828111R0M06 | AFDI00282811100M06 | AFDI00282811150M06 |
|---|---|---|---|
| Manufacturer | Chilisin Electronics | Chilisin Electronics | Chilisin Electronics |
| Product Status | Active | Active | Active |
| Type | Drum Core, Wirewound | Drum Core, Wirewound | Drum Core, Wirewound |
| Material - Core | Metal | Metal | Metal |
| Inductance | 1 µH | 10 µH | 15 µH |
| Tolerance | ±20% | ±20% | ±20% |
| Current Rating (Amps) | 90 A | 36 A | 28 A |
| Current - Saturation (Isat) | 70A | 30A | 20A |
| Shielding | Shielded | Shielded | Shielded |
| DC Resistance (DCR) | 0.49mOhm Max | 3.64mOhm Max | 4.76mOhm Max |
| Q @ Freq | - | - | - |
| Frequency - Self Resonant | - | - | - |
| Ratings | AEC-Q200 | AEC-Q200 | AEC-Q200 |
| Operating Temperature | -50°C ~ 155°C | -50°C ~ 155°C | -50°C ~ 155°C |
| Inductance Frequency - Test | 100 kHz | 100 kHz | 100 kHz |
| Features | - | - | - |
| Mounting Type | Through Hole | Through Hole | Through Hole |
| Package / Case | Radial | Radial | Radial |
| Supplier Device Package | Radial | Radial | Radial |
| Size / Dimension | 1.102" L x 1.102" W (28.00mm x 28.00mm) | 1.102" L x 1.102" W (28.00mm x 28.00mm) | 1.102" L x 1.102" W (28.00mm x 28.00mm) |
| Height - Seated (Max) | 0.429" (10.90mm) | 0.429" (10.90mm) | 0.429" (10.90mm) |
