| Part Number | AFDI002120102R2M01 | AFDI002120108R2M01 |
|---|---|---|
| Manufacturer | Chilisin Electronics | Chilisin Electronics |
| Product Status | Active | Active |
| Type | Drum Core, Wirewound | Drum Core, Wirewound |
| Material - Core | Metal | Metal |
| Inductance | 2.2 µH | 8.2 µH |
| Tolerance | ±20% | ±20% |
| Current Rating (Amps) | 46 A | 21 A |
| Current - Saturation (Isat) | 40A | 26A |
| Shielding | Shielded | Shielded |
| DC Resistance (DCR) | 1.58mOhm Max | 5.8mOhm Max |
| Q @ Freq | - | - |
| Frequency - Self Resonant | - | - |
| Ratings | AEC-Q200 | AEC-Q200 |
| Operating Temperature | -50°C ~ 155°C | -50°C ~ 155°C |
| Inductance Frequency - Test | 100 kHz | 100 kHz |
| Features | - | - |
| Mounting Type | Through Hole | Through Hole |
| Package / Case | Radial | Radial |
| Supplier Device Package | Radial | Radial |
| Size / Dimension | 0.807" L x 0.787" W (20.50mm x 20.00mm) | 0.807" L x 0.787" W (20.50mm x 20.00mm) |
| Height - Seated (Max) | 0.390" (9.90mm) | 0.390" (9.90mm) |
