| Part Number | AFDI00161311220M01 | AFDI00161311120M01 |
|---|---|---|
| Manufacturer | Chilisin Electronics | Chilisin Electronics |
| Product Status | Active | Active |
| Type | Drum Core, Wirewound | Drum Core, Wirewound |
| Material - Core | Metal | Metal |
| Inductance | 22 µH | 12 µH |
| Tolerance | ±20% | ±20% |
| Current Rating (Amps) | 9 A | 12 A |
| Current - Saturation (Isat) | 9A | 15A |
| Shielding | Shielded | Shielded |
| DC Resistance (DCR) | 25mOhm Max | 12mOhm Max |
| Q @ Freq | - | - |
| Frequency - Self Resonant | - | - |
| Ratings | AEC-Q200 | AEC-Q200 |
| Operating Temperature | -50°C ~ 155°C | -50°C ~ 155°C |
| Inductance Frequency - Test | 100 kHz | 100 kHz |
| Features | - | - |
| Mounting Type | Through Hole | Through Hole |
| Package / Case | Radial | Radial |
| Supplier Device Package | Radial | Radial |
| Size / Dimension | 0.610" L x 0.512" W (15.50mm x 13.00mm) | 0.610" L x 0.512" W (15.50mm x 13.00mm) |
| Height - Seated (Max) | 0.425" (10.80mm) | 0.394" (10.00mm) |
