| Part Number | VMMK-2503-BLKG | VMMK-3503-BLKG | VMMK-2103-BLKG | VMMK-2203-BLKG | VMMK-2303-BLKG | VMMK-2403-BLKG |
|---|---|---|---|---|---|---|
| Manufacturer | Broadcom Limited | Broadcom Limited | Broadcom Limited | Broadcom Limited | Broadcom Limited | Broadcom Limited |
| Product Status | Obsolete | Obsolete | Obsolete | Obsolete | Obsolete | Obsolete |
| Frequency | 1GHz ~ 12GHz | 500MHz ~ 18GHz | 500MHz ~ 6GHz | 900MHz ~ 11GHz | 500MHz ~ 6GHz | 2GHz ~ 4GHz |
| P1dB | 17dBm | 8dBm | 0dBm | 5dBm | 9dBm | 16.5dBm |
| Gain | 13.5dB | 12dB | 14dB | 16.5dB | 14dB | 16dB |
| Noise Figure | 3dB | 3.5dB | 2.1dB | 2dB | 2dB | 1.7dB |
| RF Type | General Purpose | 802.16 WiMAX | Cellular, PCS | General Purpose | Cellular, W-CDMA, PCS | General Purpose |
| Voltage - Supply | 5V | 3V ~ 5V | 5V | 5V | 1.8V | 3V |
| Current - Supply | 68mA | 58mA | 23mA | 25mA | 21mA | 37mA |
| Test Frequency | 6GHz | 6GHz | 3GHz | 6GHz | 3GHz | 3GHz |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount |
| Package / Case | 0402 (1005 Metric) | 0402 (1005 Metric) | 0402 (1005 Metric) | 0402 (1005 Metric) | 0402 (1005 Metric) | 0402 (1005 Metric) |
| Supplier Device Package | 0402 | 0402 | 0402 | - | 0402 | 0402 |
